日精减速机是株式会社日精NISSEI CORPORATION.下的最主要产品，包括中小功率减速机和伺服电机用减速机。株式会社日精成立于1942年，是日本知名的综合传动产品制造商之一，为日本公众上市公司。
苏州上野机电设备有限公司销售电话：17895046997 刘经理
基本情報 | 製品名 | |
|---|---|---|
生産情報/代替品情報 | 現行製品 | |
シリーズ | サーボモータ用コンパクト高精度減速機 | |
標準価格 | - | |
標準納期[工場出荷日] | - | |
性能値 | 定格出力トルク [出力軸許容トルク] ※モータ定格回転速度3000r/minを基準 | 57.3 N・m(5.85 kgf・m) |
起動・停止時ピークトルク | 143.3 N・m(14.62 kgf・m) | |
瞬時最大許容トルク | 214.9N・m(21.93kgf・m) | |
出力軸許容 O.H.L | 2940N(300kgf) | |
内部慣性モーメント[入力軸換算] | 0.0000999kg・㎡ | |
出力軸許容スラスト荷重 | 1050N(107kgf) | |
バックラッシ精度 | 30分 | |
定格入力回転速度 | 3000r/min | |
最高入力回転速度 | 5000r/min | |
連続定格入力トルク | 2.4N・m | |
減速機仕様 | 出力軸タイプ/取付 | 直交中空軸 |
枠番および出力軸径 | 28 mm | |
減速比 (実減速比) | 1/30 (1/30) | |
出力軸キー溝の有無 出力軸キー材の有無 | 出力軸キー溝有り 出力軸キー材無し | |
出力軸材質 | 炭素鋼 | |
定格入力モータ容量 ※3000r/min 基準 | 750W | |
サーボモータ 取付フランジ種別 | S3 | |
モータマッチング・容量形状種別一覧表 | ||
防水・防塵対応 （保護構造相当） | IP44 | |
質量・梱包 | 概略質量 | 6.6 kg |
梱包形状 | 段ボール 355×338×212 |
苏州上野机电设备有限公司销售型号：
| AFCZ15S-5L400S3 | AFCZ15S-5L400S3 |
| AFCZ18S-7.5L400S1 | AFCZ18S-7.5L400S1 |
| AFCZ18S-7.5L400S3 | AFCZ18S-7.5L400S3 |
| AFCZ18S-10L400S1 | AFCZ18S-10L400S1 |
| AFCZ18S-10L400S3 | AFCZ18S-10L400S3 |
| AFCZ22S-10L400S1 | AFCZ22S-10L400S1 |
| AFCZ22S-10L400S3 | AFCZ22S-10L400S3 |
| AFCZ22S-12L400S1 | AFCZ22S-12L400S1 |
| AFCZ22S-12L400S3 | AFCZ22S-12L400S3 |
| AFCZ22S-15L400S1 | AFCZ22S-15L400S1 |
| AFCZ22S-15L400S3 | AFCZ22S-15L400S3 |
| AFCZ22S-20L400S1 | AFCZ22S-20L400S1 |
| AFCZ22S-20L400S3 | AFCZ22S-20L400S3 |
| AFCZ22S-25L400S1 | AFCZ22S-25L400S1 |
| AFCZ22S-25L400S3 | AFCZ22S-25L400S3 |
| AFCZ22S-30L400S1 | AFCZ22S-30L400S1 |
| AFCZ22S-30L400S3 | AFCZ22S-30L400S3 |
| AFCZ28S-40L400S1 | AFCZ28S-40L400S1 |
| AFCZ28S-40L400S3 | AFCZ28S-40L400S3 |
| AFCZ28S-50L400S1 | AFCZ28S-50L400S1 |
| AFCZ28S-50L400S3 | AFCZ28S-50L400S3 |
| AFCZ28S-60L400S1 | AFCZ28S-60L400S1 |
| AFCZ28S-60L400S3 | AFCZ28S-60L400S3 |
| AFCZ18S-3L750S1 | AFCZ18S-3L750S1 |
| AFCZ18S-3L750S2 | AFCZ18S-3L750S2 |
| AFCZ18S-3L750S3 | AFCZ18S-3L750S3 |
| AFCZ18S-3L750S4 | AFCZ18S-3L750S4 |
| AFCZ18S-5L750S1 | AFCZ18S-5L750S1 |
| AFCZ18S-5L750S2 | AFCZ18S-5L750S2 |
| AFCZ18S-5L750S3 | AFCZ18S-5L750S3 |
| AFCZ18S-5L750S4 | AFCZ18S-5L750S4 |
| AFCZ22S-7.5L750S1 | AFCZ22S-7.5L750S1 |
| AFCZ22S-7.5L750S2 | AFCZ22S-7.5L750S2 |
| AFCZ22S-7.5L750S3 | AFCZ22S-7.5L750S3 |
| AFCZ22S-7.5L750S4 | AFCZ22S-7.5L750S4 |
| AFCZ22S-10L750S1 | AFCZ22S-10L750S1 |
| AFCZ22S-10L750S2 | AFCZ22S-10L750S2 |
| AFCZ22S-10L750S3 | AFCZ22S-10L750S3 |
| AFCZ22S-10L750S4 | AFCZ22S-10L750S4 |
| AFCZ28S-10L750S1 | AFCZ28S-10L750S1 |
| AFCZ28S-10L750S2 | AFCZ28S-10L750S2 |
| AFCZ28S-10L750S3 | AFCZ28S-10L750S3 |
| AFCZ28S-10L750S4 | AFCZ28S-10L750S4 |
| AFCZ28S-12L750S1 | AFCZ28S-12L750S1 |
| AFCZ28S-12L750S2 | AFCZ28S-12L750S2 |
| AFCZ28S-12L750S3 | AFCZ28S-12L750S3 |
| AFCZ28S-12L750S4 | AFCZ28S-12L750S4 |
| AFCZ28S-15L750S1 | AFCZ28S-15L750S1 |
| AFCZ28S-15L750S2 | AFCZ28S-15L750S2 |
| AFCZ28S-15L750S3 | AFCZ28S-15L750S3 |
| AFCZ28S-15L750S4 | AFCZ28S-15L750S4 |
| AFCZ28S-20L750S1 | AFCZ28S-20L750S1 |
| AFCZ28S-20L750S2 | AFCZ28S-20L750S2 |
| AFCZ28S-20L750S3 | AFCZ28S-20L750S3 |
| AFCZ28S-20L750S4 | AFCZ28S-20L750S4 |
| AFCZ28S-25L750S1 | AFCZ28S-25L750S1 |
| AFCZ28S-25L750S2 | AFCZ28S-25L750S2 |
| AFCZ28S-25L750S3 | AFCZ28S-25L750S3 |
| AFCZ28S-25L750S4 | AFCZ28S-25L750S4 |
| AFCZ28S-30L750S1 | AFCZ28S-30L750S1 |
| AFCZ28S-30L750S2 | AFCZ28S-30L750S2 |
| AFCZ28S-30L750S3 | AFCZ28S-30L750S3 |
| AFCZ28S-30L750S4 | AFCZ28S-30L750S4 |
| AFCZ32S-40L750S1 | AFCZ32S-40L750S1 |
| AFCZ32S-40L750S2 | AFCZ32S-40L750S2 |
| AFCZ32S-40L750S3 | AFCZ32S-40L750S3 |
| AFCZ32S-40L750S4 | AFCZ32S-40L750S4 |
| AFCZ32S-50L750S1 | AFCZ32S-50L750S1 |
| AFCZ32S-50L750S2 | AFCZ32S-50L750S2 |
| AFCZ32S-50L750S3 | AFCZ32S-50L750S3 |
| AFCZ32S-50L750S4 | AFCZ32S-50L750S4 |
| AFCZ32S-60L750S1 | AFCZ32S-60L750S1 |
| AFCZ32S-60L750S2 | AFCZ32S-60L750S2 |
| AFCZ32S-60L750S3 | AFCZ32S-60L750S3 |
| AFCZ32S-60L750S4 | AFCZ32S-60L750S4 |
| AFCZ12H-7.5M100S1 | AFCZ12H-7.5M100S1 |
| AFCZ12H-7.5M100S3 | AFCZ12H-7.5M100S3 |
| AFCZ12H-10M100S1 | AFCZ12H-10M100S1 |
| AFCZ12H-10M100S3 | AFCZ12H-10M100S3 |
| AFCZ15H-10M100S1 | AFCZ15H-10M100S1 |
| AFCZ15H-10M100S3 | AFCZ15H-10M100S3 |
| AFCZ15H-12M100S1 | AFCZ15H-12M100S1 |
| AFCZ15H-12M100S3 | AFCZ15H-12M100S3 |
| AFCZ15H-15M100S1 | AFCZ15H-15M100S1 |
| AFCZ15H-15M100S3 | AFCZ15H-15M100S3 |
| AFCZ15H-20M100S1 | AFCZ15H-20M100S1 |
| AFCZ15H-20M100S3 | AFCZ15H-20M100S3 |
| AFCZ15H-25M100S1 | AFCZ15H-25M100S1 |
| AFCZ15H-25M100S3 | AFCZ15H-25M100S3 |
| AFCZ15H-30M100S1 | AFCZ15H-30M100S1 |
| AFCZ15H-30M100S3 | AFCZ15H-30M100S3 |
| AFCZ18H-40M100S1 | AFCZ18H-40M100S1 |
| AFCZ18H-40M100S3 | AFCZ18H-40M100S3 |
| AFCZ18H-50M100S1 | AFCZ18H-50M100S1 |
| AFCZ18H-50M100S3 | AFCZ18H-50M100S3 |
| AFCZ18H-60M100S1 | AFCZ18H-60M100S1 |
| AFCZ18H-60M100S3 | AFCZ18H-60M100S3 |
