日本GTR株式会社日精减速机型号：H2L32R100-EM04TNJTN 带离合器
苏州上野机电设备有限公司销售电话：178-9504-6997 刘经理 微信同号
基本情報 | 製品名 | |
|---|---|---|
生産情報/代替品情報 | 現行製品 | |
シリーズ | インダクションギアモータ | |
標準価格 | - | |
標準納期[工場出荷日] | - | |
性能値 | 出力軸回転速度 ※モータ同期回転速度を基準 | 15r/min / 50Hz 18r/min / 60Hz |
出力軸許容トルク | 221 N・m / 50Hz 184 N・m / 60Hz | |
出力軸許容 O.H.L | 3820N | |
許容慣性モーメント [モータ軸換算値] | 0.0015kg・㎡ | |
減速機仕様 | 出力軸タイプ／取付 | 直交軸／脚取付 |
枠番および出力軸径 | 32 mm | |
減速比 (実減速比) | 1/100 (1/100) | |
出力軸材質 | 炭素鋼 | |
モータ仕様 | モータ種類 | 標準モータ(クラッチブレーキ付) |
モータ容量 | 0.4kW(1/2HP) | |
相数 | 三相 | |
電圧/周波数/ 定格電流/定格回転速度 | 200V / 50Hz / 2.1A / 1400r/min 200V / 60Hz / 1.8A / 1680r/min 220V / 60Hz / 1.8A / 1700r/min | |
コンデンサ | - | |
保護構造 | IP10 | |
ブレーキ仕様 | ブレーキ方式 | 励磁作動形(マグネットクローズ) |
ブレーキ電圧DC | 90V | |
対応整流器 | A200-D90(A100-D45) | |
ブレーキ容量[at75℃] | 14W(クラッチ) 16W(ブレーキ) | |
ブレーキ電流[at75℃] | 0.15A(クラッチ) 0.18A(ブレーキ) | |
静摩擦トルク | 3.92 N・m | |
動摩擦トルク[定格トルク] | 3.14 N・m | |
ブレーキ許容頻度 | 50回/分 | |
規格 | 対応規格 | 規格なし |
海外型式 | 海外型式置換え | |
質量・梱包 | 概略質量 | 17 kg |
梱包形状 | 段ボール 572×382×270 |
苏州上野机电设备有限公司销售型号：
H2L32R100-UTWB040NE
H2L32R100-UTWM040NE
H2L32R100-UTM040NN
H2L32R100-UTM040NA
H2L32R100-UTB040NN
H2L32R100-UTB040NA
H2L32R100-MM04TNNTB2
H2L32R100-UTM040WN
H2L32R100-UTM040WA
H2L32R100-MM04TWNTN
H2L32R100-UTB040WN
H2L32R100-UTB040WA
H2L32R100-UTWM040WE
H2L32M100-WM04TWNEN
H2L32R100-UTWB040WE
H2L32R100-YTM040NN
H2L32R100-YTM040NA
H2L32R100-MM04TNNTN
H2L32R100-YTB040NN
H2L32R100-YTB040NA
H2L32R100-MM04TNNTB2
H2L32R100-YTB040NZ
H2L32R100-MM04TNNTB2
H2L32R100-YTWM040NE
H2L32M100-WM04TNNEN
H2L32R100-YTWB040NE
H2L32M100-WM04TNNEV2
H2L32R100-YTM040WA
H2L32R100-MM04TWNTN
H2L32R100-YTB040WA
H2L32R100-YTB040WZ
H2L32R100-YTWM040WE
H2L32M100-WM04TWNEN
H2L32R100-YTWB040WE
H2L32R100-CTM040NN
H2L32R100-CTM040NA
H2L32R100-MM04TNNTN
H2L32R100-CTB040NN
H2L32R100-CTB040NA
H2L32R100-MM04TNNTB2
H2L32R100-CTB040NZ
H2L32R100-MM04TNNTB2
H2L32R100-CTWM040NE
H2L32M100-WM04TNNEN
H2L32R100-CTWB040NE
H2L32M100-WM04TNNEV2
H2L32R100-CTM040WA
H2L32R100-MM04TWNTN
H2L32R100-CTB040WA
H2L32R100-CTB040WZ
H2L32R100-CTWB040WE
H2L32R100-CTWM040WE
H2L32R100-YTB040PA
H2L32R100-CTB040PA
H2L32R100-YTWB040PE
H2L32R100-CTWB040PE
H2L32R100-UTJ040NN
H2L32R100-UTJ040NA
H2L32R100-MM04TNNTJ2
H2L32R100-UTJ040WN
H2L32R100-UTJ040WA
H2L32R100-YTJ040NN
H2L32R100-YTJ040NA
H2L32R100-YTJ040NZ
H2L32R100-YTJ040WA
H2L32R100-YTJ040WZ
H2L32R100-CTJ040NN
H2L32R100-CTJ040NA
H2L32R100-CTJ040NZ
H2L32R100-CTJ040WA
H2L32R100-CTJ040WZ
H2L32R100-YTJ040PA
H2L32R100-MM04TWNTJ4
H2L32R100-WM04TNNEN
H2L32R100-WM04TNNEV2
H2L32R100-WM04TWNEN
H2L32R100-WM04TWNEV4
H2L32R100-UTWB040NE
H2L32R100-UTWM040NE
H2L32R100-UTM040NN
H2L32R100-UTM040NA
H2L32R100-UTB040NN
H2L32R100-UTB040NA
H2L32R100-UTM040WN
H2L32R100-UTM040WA
H2L32R100-UTB040WN
H2L32R100-UTB040WA
H2L32R100-UTWM040WE
H2L32R100-UTWB040WE
H2L32R100-YTM040NN
H2L32R100-YTM040NA
H2L32R100-YTB040NN
H2L32R100-YTB040NA
H2L32R100-YTB040NZ
H2L32R100-YTWM040NE
H2L32R100-YTWB040NE
H2L32R100-YTM040WA
H2L32R100-YTB040WA
H2L32R100-YTB040WZ
H2L32R100-YTWM040WE
H2L32R100-YTWB040WE
H2L32R100-CTM040NN
H2L32R100-CTM040NA
H2L32R100-MM04TNNTN
H2L32R100-MM04TNNTB2
H2L32R100-MM04TNNTB2
H2L32M100-WM04TNNEN
H2L32M100-WM04TNNEV2
H2L32R100-MM04TWNTB4
H2L32M100-WM04TWNEV4
H2L32R100-UTJ040NN
H2L32R100-UTJ040NA
H2L32R100-UTJ040WN
H2L32R100-UTJ040WA
H2L32R100-MM04TNNTJ2
H2L32R100-MM04TNNTJ2
H2L32R100-MM04TNNTJ2
H2L32R100-MM04TNNTJ2
H2L32R100-MM04TWNTJ4
H2L32R100-MM04TWNTJ4
H2L32R100-WM04TNNEN
H2L32R100-WM04TNNEV2
H2L32R100-WM04TWNEN
H2L32R100-WM04TWNEV4
