日本树脂制电缆载体TSUBAKI椿本链条型号：TKP35H22-30W50R37K
苏州上野机电设备有限公司询价咨询电话：17895046997 刘先生 同微信
容易处理的树脂制电缆载体。
特点：
・容易切割。
・间距35mm/内高22mm。
| 型番 | 内幅W | 屈曲半径R | 質量 kg/m |
|---|---|---|---|
| TKP35H22-30W25R37 | 25 | 37 | 0.4 |
| TKP35H22-30W25R50 | 50 | ||
| TKP35H22-30W25R75 | 75 | ||
| TKP35H22-30W25R100 | 100 | ||
| TKP35H22-30W38R37 | 38 | 37 | 0.5 |
| TKP35H22-30W38R50 | 50 | ||
| TKP35H22-30W38R75 | 75 | ||
| TKP35H22-30W38R100 | 100 | ||
| TKP35H22-30W50R37 | 50 | 37 | 0.6 |
| TKP35H22-30W50R50 | 50 | ||
| TKP35H22-30W50R75 | 75 | ||
| TKP35H22-30W50R100 | 100 | ||
| TKP35H22-30W63R37 | 63 | 37 | 0.7 |
| TKP35H22-30W63R50 | 50 | ||
| TKP35H22-30W63R75 | 75 | ||
| TKP35H22-30W63R100 | 100 |
| 型番 | 内幅W | 屈曲半径R | 質量 kg/m |
|---|---|---|---|
| TKP35H22-40W25R37 | 25 | 37 | 0.4 |
| TKP35H22-40W25R50 | 50 | ||
| TKP35H22-40W25R75 | 75 | ||
| TKP35H22-40W25R100 | 100 | ||
| TKP35H22-40W38R37 | 38 | 37 | 0.5 |
| TKP35H22-40W38R50 | 50 | ||
| TKP35H22-40W38R75 | 75 | ||
| TKP35H22-40W38R100 | 100 | ||
| TKP35H22-40W50R37 | 50 | 37 | 0.6 |
| TKP35H22-40W50R50 | 50 | ||
| TKP35H22-40W50R75 | 75 | ||
| TKP35H22-40W50R100 | 100 | ||
| TKP35H22-40W63R37 | 63 | 37 | 0.7 |
| TKP35H22-40W63R50 | 50 | ||
| TKP35H22-40W63R75 | 75 | ||
| TKP35H22-40W63R100 | 100 |
苏州上野机电设备有限公司销售型号如下：
TKP35H22-30W[13,25]R[37,50,75,100]+[1-100/1]L-[MI,MO]
TKP35H22-30W[13,25]R[37,50,75,100]+[1-100/1]L-[FI,FO]
TKP35H22-30W[13,25]R[37,50,75,100]+[1-100/1]L-[FI,FO]-[MI,MO]
TKP35H22-30W[13,25]R[37,50,75,100]M+[1-100/1]L
TKP35H22-30W[13,25]R[37,50,75,100]M+[1-100/1]L-[MI,MO]
TKP35H22-30W[13,25]R[37,50,75,100]M+[1-100/1]L-[FI,FO]
TKP35H22-30W[13,25]R[37,50,75,100]M+[1-100/1]L-[FI,FO]-[MI,MO]
TKP35H22-40W[13,38]R100+[1-100/1]L
TKP35H22-40W[13,38]R100+[1-100/1]L-[MI,MO]
TKP35H22-40W[13,38]R100+[1-100/1]L-[FI,FO]
TKP35H22-40W[13,38]R100+[1-100/1]L-[FI,FO]-[MI,MO]
TKP35H22-40W[13,38]R100M+[1-100/1]L
TKP35H22-40W[13,38]R100M+[1-100/1]L-[MI,MO]
TKP35H22-40W[13,38]R100M+[1-100/1]L-[FI,FO]
TKP35H22-40W[13,38]R100M+[1-100/1]L-[FI,FO]-[MI,MO]
TKP35H22-40W[13,38]R[37,50,75]+[1-100/1]L
TKP35H22-40W[13,38]R[37,50,75]+[1-100/1]L-[MI,MO]
TKP35H22-40W[13,38]R[37,50,75]+[1-100/1]L-[FI,FO]
TKP35H22-40W[13,38]R[37,50,75]+[1-100/1]L-[FI,FO]-[MI,MO]
TKP35H22-40W[13,38]R[37,50,75]M+[1-100/1]L
TKP35H22-40W[13,38]R[37,50,75]M+[1-100/1]L-[MI,MO]
TKP35H22-40W[13,38]R[37,50,75]M+[1-100/1]L-[FI,FO]
TKP35H22-40W[13,38]R[37,50,75]M+[1-100/1]L-[FI,FO]-[MI,MO]
TKP35H22-HS38
TKP35H22-HS50
TKP35H22-HS63
TKP35H22-ST
TKP35H22M-ST
TKP35H22W25-FI
TKP35H22W25-FO
TKP35H22W25-MI
TKP35H22W25-MO
TKP35H22W25M-FI
TKP35H22W25M-FO
TKP35H22W25M-MI
TKP35H22W25M-MO
TKP35H22W38-FI
TKP35H22W38-FO
TKP35H22W38-MI
TKP35H22W38-MO
TKP35H22W38M-FI
TKP35H22W38M-FO
TKP35H22W38M-MI
TKP35H22W38M-MO
TKP35H22W50-FI
TKP35H22W50-FO
TKP35H22W50-MI
TKP35H22W50-MO
TKP35H22W50M-FI
TKP35H22W50M-FO
TKP35H22W50M-MI
TKP35H22W50M-MO
TKP35H22W63-FI
TKP35H22W63-FO
TKP35H22W63-MI
TKP35H22W63-MO
TKP35H22W63M-FI
TKP35H22W63M-FO
TKP35H22W63M-MI
TKP35H22W63M-MO
